Magnetic Angle Sensor
Pulse Width Modulation Control
REEFS LINK required for Programming
(Optional) Comes as Servo
Voltage 6-8.4 / Internal: Steel Gears
CNC Aluminum Casing / Bearing Type: 2BB
Temp Rate: -15C~ +70C
Weight: .74oz / 21g
Dimension: (LWH) .90 x .47 x 1.08 in (23 x 12 x 27.5 mm)
Torque: 135oz @ 6.0v
159oz @ 7.4v
179oz @ 8.4v
Speed: .09sec @ 6.0v
.07sec @ 7.4v
.06sec @ 8.4v
Spline: 25T Micro / Dead Band Width: 2s
Unload Current: 150mA @ 4.8V 180mA @ 6.0V 240mA @ 7.4V 300mA @ 8.4V
Load Current: 1600mA @ 4.8V 2000mA @ 6.0V 2200mA @ 7.4V 2400mA @ 8.4V
