Associated RC104WD Factory Team Buggy Kit

Associated RC104WD Factory Team Buggy Kit

Alternative Views:


Item can be pre-ordered now! Available soon
List Price: $719.99
Your Price: $479.95

Quantity in Stock:(Out of Stock)

Free Shipping
Product Code: ASC6055
Qty:

Description

Available for pre-order now!

The Team Associated RC10 4WD Factory Team is Engineered for Victory!
With over 40 years of racing heritage, the RC10 platform remains an icon, now evolved by the AREA 51 Factory Team to dominate modern tracks. This ultimate edition features a bronze anodized 6061-T6 aluminum monocoque chassis paired with Kashima coated 13mm Big Bore shocks and low CG carbon fiber towers for elite handling. The race-proven Stealth transmission and V2 slipper clutch provide a durable powerhouse. Completed with all-black plastics, a sleek Mirage Pro body, and a B7 rear wing, this kit delivers a factory level setup that seamlessly blends vintage soul with cutting edge performance



RC10 4WD Factory Team Kit Features:
Bronze anodized 6061-T6 aluminum monocoque 4WD tub chassis
Bronze anodized nose plate and cut motor plate
Exclusive black anodized nose tubes
Black anodized aluminum chassis stiffeners
Black anodized thumb nuts
All black plastics
New Mirage Pro clear lexan body
B7 rear wing included
Factory Team captured hinge pins all around
New Carbon Fiber steering plates
New Rear Carbon fiber shock tower integrates B6 wing mount
Kashima coated 13mm big bore factory team shocks included
New lower CG carbon fiber front and rear shock towers (Big bore compliant)
Factory Team 12mm hex front axle and rear CVA’s
B84 12mm hex white wheels included
Carbon Fiber transmission brace
CNC Blue anodized pulley flanges
New servo mount and belt guide system
Fully adjustable four-wheel independent suspension
Race proven front and rear Stealth transmissions
Adjustable ball differentials front and rear
Exceptional ground clearance with low center of gravity
Precision bearings throughout
Adjustable heavy duty 3.5mm turnbuckles and ball cups all around
Front and rear CVA driveshafts with 12mm Hex front and rear
Durable low friction center belt and tension system
Long front arm geometry
New front caster and spindle assembly designed for RC104WD
Updated rear bulkhead and chassis stiffener
HD Metric Ball Studs throughout
Race Proven V2 Slipper Clutch System
All new 4wd Worlds style Specific Bell Crank system

Specs:
Length: 381mm (15in)
Width: 241mm (9.49in)
Wheelbase: 273mm (10.75in)
Internal Gear Ratio: 2.6:1
Drive: 4WD
* This vehicle comes as a kit and must be fully assembled by the user. Electronics and/or an engine/motor may be required.


Required to Complete
1:10 scale 540-size electric RC car motor
1:10 scale radio control electronic speed control
7.4V-7.6V 2S LiPo with "shorty" battery dimensions (standard or low-profile height)
Battery charger (for one of the batteries mentioned above)
2-channel RC surface transmitter and its batteries
Lexan specific spray paint for body
Steering Servo
