The SPM4649T quad racing serial receiver offers full-range performance with integrated telemetry providing FPV racing enthusiasts with a serial receiver that can transmit vital telemetry data. Like SPM4648, the 4649T offers a 1-wire serial connection that is compatible with most flight controllers and an input for telemetry data such RPM, battery voltage and a whole lot more. Spektrum enthusiasts with telemetry capable transmitters such as the DX6, DX8, DX9 or DX18 can now receive on-demand telemetry data, and by using the voice functionality of compatible G2 transmitters, can have specific telemetry data outputted via the on-board audio system.
- Small size and lightweight design
- Works with most popular flight controllers
- Single line connection provides output to FC while receiving telemetry input from FC or battery
- Dual antennas for optimal range and RF performance
- Telemetry options include:
- Provided directly from receiver
- Flight log data
- Battery voltage
- RPM
- Lap Timer
- Provided by external device e.g.: Flight Controller
- Flight log if using more than 1 receiver
- Battery voltage
- RPM
- Lap Timer
- Current draw and total mAh consumption
- Temperature
- All other data the FC can send that we support such as GPS, accelerometer date, ESC data, etc...
Height:
0.2 inch (6mm)
Length:
1.2 inch (30mm)
Telemetry:
Yes
Voltage Range:
Vbatt Port 6.0v-25.2v,Receiver 4.0v-7.5v
Weight:
0.1 ounce (3 grams)
Width:
0.6 inch (16mm)
|
|
|
 |
|
 |
|
